6. OTHER FUNCTIONS
6-3
6.3 Choosing EGC Receiving Channel
EGC channel can be selected when the terminal unit is set to operate as an
EGC-only receiver. However, this procedure is shown for reference only;
currently there is only one EGC channel per NCS.
1. Press the [F7] key to display the Options menu.
Options
1. Login
2. Logout
3. Abort
4. Select EGC Ch.
5. LES Information
6. Test
Options menu (when FELCOM 16 functions as EGC receiver)
2. Press the [4] key to choose Select EGC Ch.
35:00.00N
135:00.00E
EGC Channel List
12580* 10840* 11088*
ENTER: Set ESC: Quit
11080*
EGC channel list
3. Choose desired channel and then press the [Enter] key.
4. Press the [Esc] key to return to the standby display.
