5 Hardware Description
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
10
3
Slide-out label plate (with
an SN label)
-
-
⚫
8 x 3.5" drive configuration
Figure 5-2 Front view
1
Drives
2
Slide-out label plate (with
an SN label)
⚫
12 x 3.5" drive configuration
Figure 5-3 Front view
1
Drives
2
Slide-out label plate (with
an SN label)
⚫
20 x 2.5" (8 x SAS/SATA + 12 x NVMe) drive configuration
