5.4.2.2 Memory Subsystem Architecture
The 2288H V5 provides 24 memory slots. Each processor integrates six memory
channels, and each memory channel supports up to one DCPMM.
DCPMMs must be used with DDR4 memory modules.
Table 5-7 Memory channels
CPU
Memory Channel
Memory Slot
CPU 1
A (primary)
DIMM000(A)
A
DIMM001(G)
B (primary)
DIMM010(B)
B
DIMM011(H)
C (primary)
DIMM020(C)
C
DIMM021(I)
D (primary)
DIMM030(D)
D
DIMM031(J)
E (primary)
DIMM040(E)
E
DIMM041(K)
F (primary)
DIMM050(F)
F
DIMM051(L)
CPU 2
A (primary)
DIMM100(A)
A
DIMM101(G)
B (primary)
DIMM110(B)
B
DIMM111(H)
C (primary)
DIMM120(C)
C
DIMM121(I)
D (primary)
DIMM130(D)
D
DIMM131(J)
E (primary)
DIMM140(E)
E
DIMM141(K)
