Fusion FusionServer 2288H V5 User Manual

FusionServer 2288H V5 Server
Technical White Paper
5 Hardware Description
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
71
PCIe
Slot
CPU
PCIe
Stand
ards
Conne
ctor
Width
Bus
Width
Port
No.
Root
Port
(B/D/F
)
Devic
e
(B/D/F
)
Slot
Size
the server is fully configured with PCIe devices. The values may vary if the
server is not fully configured with PCIe devices or if a PCIe card with a PCI
bridge is configured.
⚫
Root Port (B/D/F) indicates the B/D/F of an internal PCIe root port of the
processor.
⚫
Device (B/D/F) indicates the B/D/F (displayed on the OS) of an onboard or
extended PCIe device.
⚫
The PCIe x16 slots are backward compatible with PCIe x8, PCIe x4, and PCIe
x1 cards. The PCIe cards are not forward compatible. That is, the PCIe slot
width cannot be smaller than the PCIe card link width.
⚫
Full-height full-length PCIe slots are backward compatible with full-height
half-length and half-height half-length PCIe cards. Full-height half-length PCIe
slots are backward compatible with half-height half-length PCIe cards.
⚫
All slots support PCIe cards of up to 75 W. The power of a PCIe card varies
depending on its model.
⚫
The SP520, SP521, and SP522 do not support driveless server configuration.
PXE boot is recommended for driveless servers.
5.8 PSUs
⚫
The server supports one or two PSUs.
⚫
The server supports AC or DC PSUs.
⚫
The PSUs are hot-swappable.
⚫
The server supports two PSUs in 1+1 redundancy.
⚫
The same model of PSUs must be used in a server.
⚫
The PSUs are protected against short circuit. Double-pole fuse is provided for the
PSUs with dual input live wires.
⚫
If the DC power supply is used, purchase the DC power supply that meets the
requirements of the safety standards or the DC power supply that has passed the
CCC certification.
⚫
Contact your local sales representative or use the Compatibility Checker to
determine the components to be used.
⚫
When one or two 900 W AC Titanium PSUs are configured and the input voltage ranges
from 100 V AC to 127 V AC, the output power decreases to 550 W.
⚫
When one or two 1500 W AC Platinum PSUs are configured:
⚫
When the input voltage ranges from 100 V AC to 127 V AC, the output power decreases to
1000 W.
⚫
Two 1500 W AC Platinum PSUs can serve as 1700 W PSUs.

Fusion FusionServer 2288H V5 Specifications

General

Brand	Fusion
Model	FusionServer 2288H V5
Category	Server
Language	English
