Fusion FusionServer 2288H V5 User Manual

FusionServer 2288H V5 Server
Technical White Paper
5 Hardware Description
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
12
an SN label)
5.1.2 Indicators and Buttons
Indicator and Button Positions
⚫
8 x 2.5" drive configuration
Figure 5-7 Indicators and buttons on the front panel
1
Connection status indicator
for 10GE LOM port 1
2
Connection status indicator
for 10GE LOM port 2
3
Connection status indicator
for GE LOM port 1
4
Connection status indicator
for GE LOM port 2
5
Non-Maskable Interrupt
(NMI) button
6
Fault diagnosis LED
7
Health status indicator
8
UID button/indicator
9
Power button/indicator
-
-
⚫
8 x 3.5" drive configuration
Figure 5-8 Indicators and buttons on the front panel
1
Connection status indicator
for 10GE LOM port 1
2
Connection status indicator
for 10GE LOM port 2
3
Connection status indicator
for GE LOM port 1
4
Connection status indicator
for GE LOM port 2
5
Fault diagnosis LED
6
Health status indicator
