6 Product Specifications
6.1 Technical Specifications
6.2 Environmental Specifications
6.3 Physical Specifications
6.1 Technical Specifications
Table 6-1 Technical Specifications
Supports one or two processors.
⚫
Intel
®
Xeon
®
Scalable (Skylake and Cascade Lake)
processors
⚫
Built-in memory controller and six memory channels
⚫
Built-in PCIe controller, supporting PCIe 3.0 and 48
lanes per processor
⚫
Two UPI buses between processors, providing up to
10.4GT/s transmission per channel
⚫
Up to 28 cores per processor
⚫
Max. 3.8 GHz
⚫
Min. 1.375 MB L3 cache per core
⚫
Max. 205 W TDP
NOTE
The preceding information is for reference only. Use the
Compatibility Checker to obtain specific information.
Supports 24 memory modules of the following types:
⚫
Up to 24 DDR4 memory modules
− Max. 2933 MT/s memory speed
To Next Page
