FusionServer 2288H V5 Server

Technical White Paper

5 Hardware Description

Issue 11 (2023-04-30)

5.10 Boards

5.10.1 Mainboard

⚫

BOM code for mainboards of enhanced management chip (VB): 0302021706, 0302Y076.

⚫

BOM code for mainboards of normal management chip: 03024AFQ, 03026NEA, 06410432,

03024CXS, 03029JRP, 06410436, 06410592.

Figure 5-69 2288H V5 mainboard (BOM: 03024AFQ, 03026NEA, 03024CXS, 03029JRP,

0302021706, 0302Y076, 06410432, 06410436, 06410592)

USB 3.0 port (USB 3.0

CONN/J169)

UID indicator (D6020)

Serial port

Management network port

GE electrical port
