FusionServer 2288H V5 Server
Technical White Paper
5 Hardware Description
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
74
7
VGA connector (VGA
CONN/J112)
8
10GE optical port (10GE
PORT2/J132) or 10GE
electrical port (10GE
PORT2/J101)
a
9
10GE optical port (10GE
PORT1/J131) or 10GE
electrical port (10GE
PORT1/J100)
a
10
VROC key port (J130)
b
11
PCIe riser 1 slot
(corresponding to CPU
1/J108)
12
Rear drive backplane
power connector 2 (REAR
BP PWR2/J126)
13
NC-SI connector (NCSI
CONN/J99)
14
SATA signal connector 2
(SATA2/J71)
15
SATA signal connector 1
(SATA1/J67)
16
CPU 1 slimline connector
(CPU1 SLIMELINE/J170)
17
Mini SAS HD connector C
(MINIHD PORT C/J85)
18
Mini-SAS HD connector B
(MINIHD PORT B/J84)
19
Mini SAS HD connector A
(MINIHD PORT A/J86)
20
Rear drive backplane
power connector 1 (REAR
BP PWR1/J127)
21
USB 3.0 port (FRONT
USB3.0/J173)
c
22
Right mounting ears
connector
(RCIC/RCIF/RCIG
BOARD/J167)
23
TPM/TCM port (TPM
CONN/J55)
24
LCD connector (LCD
CONN/J87)
25
VGA connector (VGA
BOARD/J160)
26
Fan 4 connector (2U
FAN4/J148)
27
Fan 3 connector (2U
FAN3/J145)
28
Fan 2 connector (2U
FAN2/J146)
29
Fan 1 connector (1U/2U
FAN1/J105)
30
Drive backplane connector
(HDD BP CONN/J162)
31
RTC battery (CMOS
BATTERY/U4042)
32
Inner drive power
connector (INNER HDD
PWR/J171)
33
Drive backplane power
connector 1 (HDD BP
PWR2/J128)
34
Drive backplane power
connector 2 (HDD BP
PWR2/J166)
35
Rear drive backplane
power connector 3 (REAR
BP PWR3/J172)
36
Rear 4 x 2.5" drive
backplane low-speed
signal connector (REAR
4*2.5 HDD BP/J164)
37
CPU2 slimline A connector
38
CPU2 slimline B connector
