FusionServer 2288H V5 Server
Technical White Paper
5 Hardware Description
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
9
5 Hardware Description
5.1 Front Panel
5.2 Rear Panel
5.3 Processor
5.4 Memory
5.5 Storage
5.6 Network
5.7 I/O Expansion
5.8 PSUs
5.9 Fans
5.10 Boards
5.1 Front Panel
5.1.1 Appearance
⚫
8 x 2.5" drive configuration
Figure 5-1 Front view
1
Drives
2
(Optional) Built-in DVD
drive
