FusionServer 2288H V5 Server
Technical White Paper
Copyright © xFusion Digital Technologies Co., Ltd.
transmission
status indicator
⚫
Blinking green: Data is being
transmitted.
⚫
Steady green: The network port is
properly connected.
Connection status
indicators
⚫
Off: No physical link is set up.
⚫
Blinking green: The physical link is
abnormal.
⚫
Steady green: The physical link is
normal.
Data transmission
status indicator
⚫
Off: No logical link is set up.
⚫
Blinking yellow: Data is being
transmitted.
⚫
Steady yellow: The logical link is
normal but no data is being
transmitted.
5.7 I/O Expansion
5.7.1 PCIe Cards
PCIe cards provide ease of expandability and connection.
⚫
The electrical ports provided by PCIe NICs cannot be connected to power over
Ethernet (PoE) devices (such as a switch with PoE enabled). Connecting such an
electrical port to a PoE device may cause link communication failure or even
damage the NIC.
⚫
Contact your local sales representative or use the Compatibility Checker to
determine the components to be used.
⚫
When IB cards are used to build an IB network, ensure that the IPoIB modes of
the IB cards at both ends of the network are the same. For details, contact
technical support.
