FusionServer 2288H V5 Server
Technical White Paper
5 Hardware Description
Issue 11 (2023-04-30)
Copyright © xFusion Digital Technologies Co., Ltd.
25
Callout
Description
Definition
1
Capacity of the memory module
⚫
8 GB
⚫
16 GB
⚫
32 GB
⚫
64 GB
⚫
128 GB
2
Number of ranks of the memory
module
⚫
1R: single-rank
⚫
2R: dual-rank
⚫
4R: quad-rank
⚫
8R: octal-rank
3
Data width on the DRAM
⚫
X4: 4-bit
⚫
X8: 8-bit
4
Type of the memory interface
⚫
PC3: DDR3
⚫
PC4: DDR4
5
Maximum memory speed
⚫
2133 MT/S
⚫
2400 MT/S
⚫
2666 MT/S
⚫
2933 MT/S
⚫
3200 MT/S
6
Column Access Strobe (CAS)
latency
⚫
P: 15
⚫
T: 17
7
DIMM type
⚫
R: RDIMM
⚫
L: LRDIMM
5.4.1.2 Memory Subsystem Architecture
The 2288H V5 provides 24 memory slots. Each processor integrates six memory
channels.
Install the memory modules in the primary memory channels first. If the primary
memory channel is not populated, the memory modules in secondary memory
channels cannot be used.
Table 5-5 Memory channels
CPU
Memory Channel
Memory Slot
CPU 1
A (primary)
DIMM000(A)
A
DIMM001(G)
B (primary)
DIMM010(B)
B
DIMM011(H)
