FusionServer 2288H V5 Server

Technical White Paper

3 Physical Structure

Issue 11 (2023-04-30)

3 Physical Structure

Figure 3-1 2288H V5 physical structure (example: 12 x 3.5" drives)

I/O module 1

I/O module 2

Power supply unit (PSU)

I/O module 3

Chassis

(Optional) built-in drive

module

Supercapacitor holder

(Optional) air duct

Front drive backplane

Fan module bracket

Fan modules

Front drive
