FusionServer 2288H V5 Server
Technical White Paper
Copyright © xFusion Digital Technologies Co., Ltd.
even damage the NIC.
⚫
Forcibly powering off a server will cause intermittent NC-SI
disconnection and disable the WOL function of the LOM
ports. To restore the NC-SI connection, refresh the iBMC
WebUI.
10 PCIe 3.0 slots:
⚫
One slot dedicated for a screw-in RAID controller card,
one dedicated for a FlexIO card, and eight for standard
PCIe cards.
For details, see 5.7.2 PCIe Slots and 5.7.3 PCIe Slot
Description.
⚫
Support PCIe SSD cards to bolster I/O performance
for applications such as searching, caching, and
download services.
⚫
Supports GPU cards.
⚫
When IB cards are used to build an IB network, ensure
that the IPoIB modes of the IB cards at both ends of
the network are the same. For details, contact
technical support.
NOTE
The preceding information is for reference only. Use the
Compatibility Checker to obtain specific information.
Supports a variety of ports.
⚫
Ports on the front panel:
− Two USB 2.0 ports
− One USB 3.0 port
− One DB15 VGA port
NOTE
For the server that uses 12 x 3.5", 20 x 2.5" (8 x SAS/SATA + 12 x
NVMe) or 25 x 2.5" drive configuration, the front panel provides
only two USB 2.0 ports.
⚫
Ports on the rear panel:
− Two USB 3.0 ports
− One DB15 VGA port
− One RJ45 serial port
− One RJ45 system management port
− Two GE electrical ports
− Two 10GE electrical ports or 10GE optical ports
⚫
Built-in ports:
− One USB 3.0 port
− Two SATA ports
NOTE
In the 8 x 2.5" or 24 x 2.5" drive configuration, only two SATA
built-in ports are provided.
NOTE
