35
and the neutral position of the servos will shift. Keep in mind that you should start out with the control
adjust the trims once airborne.
Each of the trim levers features an audible tone, or beep, that alerts you when the trim is activated.
Additionally, there is a double-beep and a slight pause that occurs when the trim lever is centered (zeroed).
adjustments are required, land the model and then enter the program as described below to adjust the trims in
Note:
however, it is not necessary to start from the beginning.
Center the servos:
1) Turn on the transmitter and receiver. Operate the controls to make sure the servos respond in the correct
direction. Use the reversing function to reverse any servos necessary.
2) Center the throttle control stick.
3) Place the servo arms on the servos so they are perpendicular to the pushrods (see page
??). It is okay to
cut off any unused servo arms.
4) Connect the pushrods to the control surfaces. Adjust the length of the pushrods until the control surfaces
are centered when the servos are centered.
Once the servos and control surfaces have been connected and the control throws have been set using the end
and level.
1) If the transmitter is off, turn it on at this time.
2) Press and hold the MODE button to access the programming mode.
3) Press either the MODE key OR the END key to scroll through the function menus.
Continue pressing the MODE or END key until the trim (TRIM) menu appears on
screen.
To Next Page
