57
12) Press and hold the END button to exit the programming mode.
Swash to throttle mixing (SW-T)-(HELI only)
When idle up is activated, this predetermined mixing function is used to prevent the engine from slowing, or
To activate swash to throttle mixing:
1) Turn the transmitter on.
2) Press and hold the MODE button to access the programming mode. An audible double beep will be heard
and the default screen will change.
3) Press either the MODE key OR the END key to scroll through the function menus.
Continue pressing the MODE or END key until the swashplate to throttle (SW-T)
mixing menu appears on screen.
4) Press the SELECT key to display the CH-A. This indicates that the values which
will be adjusted are the values of the aileron input.
5) Press the DATA INPUT lever to set the percentage of aileron to throttle mixing rate
from 0-100%.
6) Press the SELECT key to display the CH-E. This indicates that the values which
will be adjusted are the values of the elevator input.
7) Press the DATA INPUT lever to set the percentage of elevator to throttle mixing
rate from 0-100%.
5) Press the SELECT key to display the CH-4. This indicates that the values which will be adjusted are the
values of the rudder input.
6) Press the DATA INPUT lever to set the percentage of elevator to throttle mixing rate from -100% to
Swash Ring (RING)-
swash linkages from simultaneous operation of the aileron and elevator inputs. That is, this is basically an
electronic version of a former mechanical action that prevented binding of the controls when the elevator/
