36
adjustments for CH1).
but if the DATA INPUT lever is held long enough the values will change more rapidly.
6) Press the SELECT key to bring forth the trim values for the remaining channels. To change the values for
these channels, repeat step 3 above for each channel that requires trim adjustments.
7) Press and hold the END button to exit the programming mode.
Note:
To view the trim settings:
view the trim setting adjustments.
1) Turn the transmitter on. If the transmitter is already on, ensure that it is in the default display mode.
2) With the home page displayed, press and hold the END key. The T6J will then scroll through the trim
settings for each of the respective channels. The channel is indicated on the left side of the screen; whereas
the trim input will be located on the right side of the LCD.
Sub-Trims (STRM)-
The sub-trims are generally used to off-set the center position of the servos if you are unable to achieve
perfect mechanical linkages. The T6J transmitter allows for sub-trim adjustments on all six channels. Rather
Ensure that the linkages are as perfect as possible prior to adjusting the sub-trims. Extremely high sub-trim
To adjust the Sub-Trim settings:
1) Turn the transmitter on.
2) Press and hold the MODE button to access the programming mode.
3) Press either the MODE key OR the END key to scroll through the function menus. Each time one of the
aforementioned keys is pressed the menu will change accordingly. Continue pressing the MODE or END
To Next Page
