51
Note: As with all switch selection availability, if the modeler has programmed any other functionality to this
switch selection, the idle up throttle curve and the other function will be activated simultaneously. As such, it
is imperative to ensure that these desired functions will not negatively impact one another.
For example, if the modeler has programmed Switch B to activate the low rates, and then selected Switch B
as the activation switch for the idle up curves, moving Switch B will activate both functions simultaneously.
Note: if the trainer function is activated, the switch C is allocated for the trainer function automatically.
9) Press and hold the END button to exit the programming mode.
Pitch Curve Idle UP (I-PI) - (HELI only)




A 5-point pitch curve is utilized to best match the blade collective pitch to the engine RPM for consistent
load on the engine. The curve can be adjusted from 0-100% each point. Idle up creates a curve typically

even when the stick is pulled all the way back. This is one of the functions that makes the maneuvers such as



Point 1- the collective servo is at the desired lowest point with the throttle stick at the lowest (bottom)
position. This is normally full negative pitch.
Point 2- the collective servo is at the desired point with the throttle stick is advanced ¼ of the way.
Point 3- the collective servo is at the desired point with the throttle stick advanced ½ way.
Point 4- the collective servo is at the desired point with the throttle stick advanced ¾ of the way.
Point 5- the collective servo is at the desired point with the throttle stick fully advanced. This is full positive
pitch.
To set the idle up pitch curve:
1) Turn the transmitter on.
2) Press and hold the MODE button to access the programming mode. An audible
double beep will be heard and the default screen will change accordingly.
3) Press either the MODE key OR the END key to scroll through the function menus.
Continue pressing the MODE or END key until the idle up pitch curve (I-PI) menu
