13 IN8 I Input 8
14 XLATCH I Input 1 (Used for X axis latch input)
14 YLATCH I Input 2 (Used for Y axis latch input)
14 ZLATCH I Input 3 (Used for Z axis latch input)
14 WLATCH I Input 4 (Used for W axis latch input)
15 +5V O + 5 volts
15 +12V O +12 volts
15 -12V O -12 volts
15 ANA GND O
Isolated Analog Ground for Use with Analog
Inputs
16 INCOM I Input Common For General Use Inputs
16 ABORT I Abort Input
16 RESET I Reset Input
16 GND O Signal Ground
17 ANALOG5 I Analog Input 5
17 ANALOG6 I Analog Input 6
17 ANALOG7 I Analog Input 7
17 ANALOG8 I Analog Input 8
18 ANALOG1 I Analog Input 1
18 ANALOG2 I Analog Input 2
18 ANALOG3 I Analog Input 3
18 ANALOG4 I Analog Input 4
19 +5V O + 5 volts
19 +INX I X Main encoder Index +
19 -INX I X Main encoder Index -
19 GND O Signal Ground
20 +MAX I X Main encoder A+
20 -MAX I X Main encoder A-
20 +MBX I X Main encoder B+
20 -MBX I X Main encoder B-
21 +5V O + 5 volts
21 +INY I Y Main encoder Index +
21 -INY I Y Main encoder Index -
21 GND O Signal Ground
22 +MAY I Y Main encoder A+
22 -MAY I Y Main encoder A-
22 +MBY I Y Main encoder B+
22 -MBY I Y Main encoder B-
23 +5V O + 5 volts
23 +INZ I Z Main encoder Index +
23 -INZ I Z Main encoder Index -
23 GND O Signal Ground
DMC-2X00 Appendices y 209
