66 OUT1 O Output 1
67 OUT2 O Output 2
68 OUT3 O Output 3
69 OUT4 O Output 4
70 OUT5 O Output 5
71 OUT6 O Output 6
72 OUT7 O Output 7
73 OUT8 O Output 8
74 GND Signal Ground
75 AN1 I Analog Input 1
76 AN2 I Analog Input 2
77 AN3 I Analog Input 3
78 AN4 I Analog Input 4
79 AN5 I Analog Input 5
80 AN6 I Analog Input 6
81 AN7 I Analog Input 7
82 AN8 I Analog Input 8
83 +MAX I X Main encoder A+
84 -MAX I X Main encoder A-
85 +MBX I X Main encoder B+
86 -MBX I X Main encoder B-
87 +INX I X Main encoder Index +
88 -INX I X Main encoder Index -
89 ANA GND Analog Ground
90 +VCC + 5 volts
91 +MAY I Y Main encoder A+
92 -MAY I Y Main encoder A-
93 +MBY I Y Main encoder B+
94 -MBY I Y Main encoder B-
95 +INY I Y Main encoder Index +
96 -INY I Y Main encoder Index -
97 +MAZ I Z Main encoder A+
98 -MAZ I Z Main encoder A-
99 +MBZ I Z Main encoder B+
100 -MBZ I Z Main encoder B-
101 +INZ I Z Main encoder Index +
102 -INZ I Z Main encoder Index -
103 GND Signal Ground
104 +VCC + 5 volts
105 +MAW I W Main encoder A+
106 -MAW I W Main encoder A-
107 +MBW I W Main encoder B+
DMC-2X00 Appendices y 217
