Gatekeeper Y58 - Page 126

Y58 User Manual & Install Guide
126 of 148
Section Limit Speed
TTS Switch
DEFAULT SETTINGS:
Checkbox – unselected
T&H Sensor
Name
T-Sensor1, name of the Sensor.
Enable
DEFAULT SETTINGS:
Checkbox – unselected
Alarm Type
DEFAULT SETTINGS:
Alarm
Trigger
High Temp. Thresh
DEFAULT SETTINGS:
284° F
Temp. Increase Warn Time
DEFAULT SETTINGS:
10 Minutes
Temp. Increase Difference
DEFAULT SETTINGS:
154° F
Debounce Time – multiple alarms of the same resource
active within the debounce time frame are regarded as
one alarm.
DEFAULT SETTINGS:
10 Seconds
Linkage
Click the (Setup) button under Linkage to go to the
Linkage setup screen. This sets up the video display,
recording and snapshot options associated with this
alarm.
The Linkage setup screen enables you to configure the
following options:
Channel – checkboxes that allow you to select
any combination of the camera channels to be
included in the display and recording.
Post Recording – numeric value box which
allows you to enter the duration for which video
will continue to be recorded when the alarm is
triggered.
Lock – checkbox, if selected will mark the
recorded video associated with this alarm as a
locked video.
Linkage IO Output – checkboxes, if enabled,
the device will send a signal to the selected IO
output lines.
