Y58 User Manual & Install Guide
Note that at any other
screen, the Exit button
returns you to the previous
screen.
Not applicable. Use the on-
screen controls.
Press the Menu button on
the ICD2.
Jump to a particular
channel.
Not applicable. Use the on-
screen controls.
While viewing a video, press
any one of the numbered
buttons (from 1 to 9) on the
numeric keypad of the ICD2,
or double-tap the channel
on the screen to switch to
the corresponding channel.
Cycle to the next
channel.
Not applicable. Use the on-
screen controls.
Press the (0) button on the
numeric keypad of the ICD2.
Playback controls for
video.
When you are viewing video
playback, press the Right
Button to display/hide the
on-screen video playback
controls.
You may then use the on-
screen controls to adjust the
video playback.
When you are viewing video
playback, tap anywhere on
the screen to display/hide
the on-screen video
playback controls.
You may then use the on-
screen controls to adjust the
video playback.
3.3 The Y58 Start-up Screen Layout
Upon start-up, the screen of the Y58 will display the live video streams from the various cameras
attached to the Y58. Users can select and configure how many video channels to be displayed on the
screen for monitoring purposes. The screen also serves as an interface into the menu system of the Y58
where users can playback recorded video and access the configuration menu to change the device
configuration settings.
The screen layout will stay the same regardless of whether an ICD2 is being used, or an LCD monitor
being used along with a Finger Mouse. This ensures that the user always has a familiar interface and
consistent methodology to interact with the menu system and device functions.
