Gatekeeper Y58 - Page 15

Y58 User Manual & Install Guide
15 of 148
32GB, 64GB, 128GB, 256GB
Recording
Recording Trigger
Recording Trigger Schedule, alarms, sensor triggers
Pre-recording
0 to 60 min
Post-recording
Max 30 min
File Size
15 min of video
Playback
DVR Video Playback
1 channel local up to 8 channels using G4 Viewer Plus
Search Method
Date/Time, channel file type, event
Network
Ethernet
Ethernet RJ 45 port (10/100M) (optional)
Cellular
External 3G or 4G cellular module (optional)
WIFI
Internal built-in WIFI 802.11ac 2.4 GHz and 5GHz or external
WIFI (optional)
Note – if you have plugged in the external Wi-Fi then only one
of them will work at a time, either external or internal.
GPS
GPS Location, Speed, Time Sync
Power
Input
Input 8 to 36V
Output
5V @ 500mA
Standby Current
<1 mA @ 12.6V
Physical
Dimensions
7.95” x 6.7” x 3.5” (202 mm x 171 mm x 89 mm)
without cable cover
10” x 6.7” x 3.5” (252 mm x 171 mm x 89 mm)
with cable cover (optional)
Weight
4.4 lbs. (2 kg)
Environmental
