CHAPTER 4: Upgrading Your Computer
46
4 Unplug the cables connected to the card reader, and
slide cables out of the clips that hold them down. Make
note of the cable locations.
5 Remove the screw that secures the card reader to the
computer, then remove the card reader.
6 Slide the new card reader into place, then secure it with
the screw you removed previously.
7 Plug the appropriate cables into the card reader.
8 Place the top bezel on top of the computer, then slide the
bezel toward the front of the computer until it clicks into
place.
9 Reinstall the front bezel by following the instructions in
“Replacing the front bezel” on page 38.
10 Reinstall the side panels by following the instructions in
“Replacing the side panels” on page 39.
Screw
To Next Page
