Concord
9
After determining panel location, run all necessary wires to that location using the guidelines in
Table 4.
Mounting the Panel
Use the following procedure to mount the panel to the wall or wall studs.
Make sure you are free of static electricity whenever you work on the panel with the cover
open. To discharge any static, first touch the metal panel chassis, then stay in contact with
the chassis when touching the circuit board. Using an approved grounding strap is recom-
mended.
¾To mount the panel (see Figure 2):
1. Open the panel door and remove the necessary wiring knockouts. Be careful not to damage
the circuit board.
2. Feed all wires through wiring knockouts and place the panel in position against the wall.
3. Level the panel and mark the top and bottom mounting holes.
4. Install anchors where studs are not present.
5. Partially insert screws into the two top mounting hole locations, then hang the panel on the
two screws.
6. Recheck for level, insert the two lower screws, and tighten all four mounting screws.
SuperBus 2000 RF Receiver 27 mA
SuperBus 2000 Phone Interface/Voice Module 25 mA
Power Line Carrier Card N/A
4 Input/2 Output SnapCard 20 mA
8Z Hardwire Zone Expander SnapCard 38 mA
4 Output SnapCard 1 mA
SuperBus 2000 8Z Input Module 18 mA
SuperBus 2000 4-Relay Output Module 12 mA
SuperBus 2000 Energy Saver Module 20 mA
SuperBus 2000 Cellular Backup Module 90 mA
SuperBus 2000 Automation Module 30 mA
SuperBus 2000 Wireless Gateway Module 55 mA
Interrogator 200 10 mA
Interrogator AVM 45 mA
Table 4: Wire Requirements
Device Wire Requirements
AC Power Transformer 2-conductor, 18-gauge, 25 feet max
Earth Ground Single conductor, 16-gauge solid, 25 feet max
Telephone (RJ-31X) 4-conductor
Detection Devices
2- or 4-conductor, 18- to 22-gauge, 300-ohms
max loop resistance including device
Speakers
2-conductor, 22-gauge, 175 feet max
2-conductor, 18-gauge, 440 feet max
SuperBus 2000 Devices 4-conductor, 22- or 18-gauge
Interrogator 200 AVM Power and Microphone 4-conductor, 22-gauge, shielded
2-Wire Smoke Detectors
2-conductor, 22-gauge, 330 feet max
2-conductor, 18-gauge, 830 feet max
(based on 10-ohms max loop resistance plus
a 2k-ohm, end-of-line resistor)
Table 3: Minimum Device Current Draw
Device Min. mA Draw
Caution
!
