Concord
49
The following sections describe the settings that appear under SIREN OPTIONS—PARTITION 1.
Sensors Menu
The SENSORS menu gives you access to the following settings:
•
LEARN SENSORS lets you add (learn) hardwire zones, wireless sensors, and wireless touch-
pads into panel memory.
•
SENSOR TEXT lets you “name” the sensors and zones you have added to the system.
•
DELETE SENSORS lets you delete zones and sensors from panel memory.
•
EDIT SENSORS lets you view and, if desired, change a sensor group or partition assignment.
You can also identify whether a zone is wireless or hardwire, whether it is configured as
Normally Closed (N/C) or Normally Open (N/O), or if the zone is a touchpad.
SWS Supv Code (0703)
Siren Options-Global (Default = 3)
This setting determines the system house code number used for supervising wireless
sirens.
Note
To supervise wireless sirens, Concord hardwire panels must include a SuperBus 2000 RF
Receiver. For all Concord panels, the siren must be learned into sensor group 33 for the sys-
tem to process radio signals from wireless sirens.
Supervised Wireless Sirens receive signals from the panel through the existing electri-
cal wiring. If sirens fail to receive or process these signals, the siren transmits a wire-
less signal to the panel/ receiver.
Note
You must set both the SWS Supv Code and the partition House Code (see the
LIGHT CON-
TROL menu) before plugging in Supervised Wireless Sirens.
¾To set the SWS Supv Code:
1. With the display showing SWS
SUPV CODE nnn
(current code),
enter the desired code (1–255).
The display flashes the entered
code.
2. Press # and the display shows the
new code.
Global Fire (0704)
Siren Options-Global (Default = off)
This setting determines whether or not sirens in both partitions sound
(on) if either partition activates a fire alarm.
¾
To turn Global Fire off or on:
1. With the display showing GLOBAL FIRE OFF/ON
(current setting), press 1 (off) or 2 (on). The dis-
play flashes the entered setting.
2. Press # and the display shows the new setting.
Siren Verify (0710)
Siren Options-Partition 1 (Default = off)
This setting determines whether or not the panel supervises the panel
speaker terminals (7–8). When this feature is on, the panel will indicate a
trouble condition if no speaker is connected to panel speaker terminals.
Note
For UL Listed installations, Siren Verify must be set to on.
¾To turn Siren Verify off or on:
1. With the display showing SIREN VERIFY OFF/
ON
(current setting), press 1 (off) or 2 (on).
The display flashes the entered setting.
2. Press # and the display shows the new setting.
Table 7: How to Trip Sensors
Sensor Steps to Trip Sensor
Hardwire Zones
Start with the zone in its “normal” state, then trip the zone into
its alarm state. A normally closed door, for example, should be
closed when you begin the Learn Sensors process. To trip the
zone, open the door.
Wireless Sensors Follow the instructions included with each sensor.
Wireless Door/Window Sensors
with External Contacts
Place the external contact in the alarm condition, then activate
the sensor tamper switch.
Self Actuated Bell Activate the tamper switch.
