• Hardwire Smoke Detector: System Sensor models 2100D, 2100TD, 2100S, 2100TS, 2400,
or 2400TH learned into sensor group 26 or Sentrol (ESL) models 429AT, 521B or 521BXT
learned into sensor group 26
• Wireless Smoke Sensor 60-506-319.5 or 60-848-02-95 learned into sensor group 26
• Immediate Beeps set to on
• UL 98 Options set to on
• Receiver Failure set to on (if wireless devices are used)
• Siren Verify set to on
• RF TX Timeout set to 4 hours (if system includes a built in or SuperBus 2000 RF Receiver
and wireless smoke sensors)
• Sleep Time set to off
• Siren Timeout set to 4 minutes or more
• Two Trip Error set to off
• Disable Trouble Beeps set to off
UL 1023 & 985 24-Hour Backup
For 24-hour backup, the total current draw for all connected devices is limited to 90 mA (during
normal standby conditions) using a 4.0 AH battery, or 190 mA (during normal standby condi-
tions) using a 7.0 AH battery.
SIA System Requirements
Note
UL requirements take prior-
ity over SIA requirements.
SIA system requirements are the same as those described for a UL Listed Basic System on page
1, plus:
• If multiple annunciation is required, use Hardwire Siren part no.13-046.
SIA Setting Requirements
The following table describes programming requirements to meet ANSI-SIA CP-01.
Shortcut # Function Programming
Page
Reference
Testing
Page
Reference
Default
Setting
Required Setting
0004 SIA False Alarm
Reduction
28 66 On On
partition 1: 0013
partition 2: 0023
Exit Extension 29 66 On On
partition 1: 0014
partition 2: 0024
Auto Stay Arming 29 66 On On
partition 1: 0017
partition 2: 0027
Duress Code 30 66 Disabled Disabled
02005 Dialer Abort 36 66 On On
02006 Dialer Abort Delay 36 66 30 Sec. 15-45 sec.
02007 Cancel Message 36 66 On On
02009 Call Wait Cancel 37 66 Disabled On if reporting to central station and
customer has call waiting service
partition 1: 0310
partition 2: 0320
Entry Delay 40 66 30 sec. 30-240 sec.
partition 1: 0311
partition 2: 0321
Exit Delay 40 66 60 sec. 45-184 sec.
06014 Swinger Limit 45 66 1 1
1100 Smoke Verify 57 66 Off On if smoke alarms are programmed
into system
N/A Cross Zoning 85 66 Disabled Enabled for zones with a high
probability of false alarms

GE Interlogix Concord Security System Specifications

General

Brand	GE Interlogix
Model	Concord Security System
Category	Security System
Language	English
