Concord
3
The following table describes non-programmable (hard coded) system operation as required to
meet ANSI-SIA CP-01 and is provided only for your reference.
Commercial Burglary Alarm System Unit (Grade C UL 1610)
Basic system using Control Panel 60-801-01 plus:
• Hardwire Magnetic Contact (13-068 or 13-071) or Wireless Learn Mode Door/Window
Sensor (60-499)
• SAW PIR Sensor (60-639-95R), Crystal PIR Sensor (60-703-95R), or DS924i PIR Sensor
(60-511-01-95)
• Immediate Beeps set to on
• UL 98 Options set to on
• Receiver Failure set to on (if wireless devices are used)
• RF TX Timeout set to 4 hours
• 24-Hour Tamper set to on
• System Tamper set to on
• Auto Phone Test set to on
• Phone Test Freq. set to 1
• Next Phone Test set to 1
• Siren Verify set to on
• AC Failure set to on
• Exit Delay set to 120 seconds or less
• Quick Exit set to off
• Two Trip Error set to off
• Alarm Verify set to off
• Disable Trouble Beeps set to off
• Phone Number must be programmed
• High Level Rpts set to on
• Low Level Rpts set to on
• Comm. Failure set to on
• Extended Delay set to off
• Sleep Time set to off
• Siren Timeout set to 4 minutes or more
UL 1610 24-Hour Backup
• Same as UL 1023 & 985
UL 1635 Digital Alarm Communicator System
Note
For UL 1635 installations,
Entry Delay plus Dialer
Abort Delay must not
exceed 60 seconds.
Same as UL 1023, 985 & 1610 plus:
• AC Failure set to on
• Phone Number must be programmed
• Low CPU Battery set to on
• Next Phone Test set to 1
• Phone Test Freq. set to 1
• High Level Rpts set to on
• Low Level Rpts set to on
• Comm. Failure set to on
• RF Tx Timeout set to 4 hours
Function Operation
Disarm During Entry Delay Enter Code Only (or 1 + CODE)
Cancel Alarm Enter Code Only (or 1 + CODE)
Abort Annunciation Enabled
Cancel Report Annunciation Enabled
