Concord
71
10. Restore previous CS PHONE 1 settings if needed.
Troubleshooting This section describes what to do if you experience problems with system operation. If after per-
forming the troubleshooting procedures the panel still malfunctions, please call Technical Sup-
port at 1-800-777-2624.
Table 13: Current Phone Settings
CS PHONE 1 Option Test Setting Previous Setting
PHONE NUMBER Central station phone number
HIGH LEVEL RPTS ON
BACKUP OFF*
CELLULAR BACKUP ON
* Can be set to ON if no CS PHONE 2 PHONE NUMBER is programmed.
Feature Problem Action/Solution
Panel Power
Panel does not power up. Touchpads don’t display or respond.
1. Verify that the panel transformer is plugged into an unswitched outlet.
2. Check the AC circuit breaker to be sure the circuit is live.
3. Check that the backup battery is installed correctly and the AC power transformer is plugged in.
4. Check for proper panel and transformer wiring.
5. Measure the incoming AC voltage at panel terminals 1 and 2. It should read about 24 VAC.
No incoming AC voltage at panel terminals 1 and 2.
1. Unplug the AC power transformer and disconnect the wires from the transformer and the panel.
2. Check transformer to panel wire for short or open circuits.
3. Plug in the transformer and check for 24 VAC at the transformer unconnected terminals. If zero
(0) volts, replace the transformer.
Touchpad display indicates System Low Battery or voice sounds “System low battery.”
1. Check that the backup battery is installed correctly and the AC power transformer is plugged in.
2. Measure the incoming AC voltage at panel terminals 1 and 2. It should read about 24 VAC.
3. Check for 11.75 to 13.5 VDC battery voltage between the backup
battery spade lugs. If the battery voltage is not within this range, replace the battery.
Note
When the panel is running a backup battery test, the reading at the connected battery can range from
11.2 to 13.5 VDC. The panel automatically runs a backup battery test under the following conditions: (1)
on initial power-up, (2) during user sensor test, (3) once every minute when backup battery has failed,
(4) once every 24 hours at the programmed STIME (UL 98 Options off) or once every 4 hours (UL 98
Options on).
With the AC power transformer plugged in, the panel automatically charges the battery. While the bat-
tery is charging for the first time it is normal for the system to indicate System Low Battery. This can take
a number of hours depending on the initial battery charge. Once the battery reaches 12.5 VDC (full
charge as measured while in battery test), the condition clears. If the trouble condition persists after 24
hours, replace the backup battery.
After pressing STATUS the touchpads flash AC or display AC Power Failure/AC Failure. (Panel continues to operate
from backup battery).
