Concord 4
Central Station Reporting
The panel has been tested with the following central station receivers using SIA and Contact ID
reporting formats:
• CS-5000 Central Station Receiver
• Sur-Gard Central Station Receiver with models SG-DRL2A and SG-CPM2
UL Canada Listed Installations
This section describes the requirements for CUL (UL Canada) Listed installations.
Canadian Standards CSA Certified Accessories
Residential Burglary Alarm System Unit (ULC-S309)
Basic system as described for “UL 1023 Listed Installations” plus:
• Hardwire Magnetic Contact (13-068 or 13-071) or Wireless Learn Mode Door/Window Sen-
sor (60-362)
• Siren Timeout set to 5 minutes or more
Residential Fire Warning System Control Unit (ULC-S545-M89)
Basic system as described for “UL 985 Listed Installations” plus:
• Hardwire Smoke Detector: System Sensor models 2100D, 2100TD, 2100S, 2100TS, 2400,
2400TH learned into Sensor Group 26, or Sentrol (ESL) models 429AT, 521B, or 521BXT
learned into sensor group 26
• Wireless Smoke Sensor 60-506-319.5 or 60-848-02-95 learned into sensor group 26
• Immediate Trouble Beeps set to on
Note
For 24-hour backup, exter-
nal power drain is limited to
90 mA (during normal
standby condition) using a
4.0 AH battery, or 190 mA
continuous using a 7.0 AH
battery.
• RF TX Timeout set to 4 hours (if system includes SuperBus 2000 RF Receiver and wireless
smoke sensors)
California State Fire Marshall Listed Installations
Same as Household Fire Warning System (UL 985), plus:
• SMOKE VERIFY must be set to off
Planning the
Installation
This section describes system capabilities to help you get familiar with the system. “Appendix
A” provides planning sheets with tables that let you record the hardware and programming con-
figuration of the system. Fill in all necessary information ahead of time to help prepare for sys-
tem installation.
When planning the installation, keep in mind that the panel has the following capabilities (depen-
dent upon devices used):
• Up to 16 SuperBus 2000 Devices (maximum of 4 RF receivers)
• Up to 96 wireless or hardwired zones
Standard Panel
The following describe the basic panel (out-of-box) hardware capabilities.
• Power: Input for an AC step-down, plug-in style transformer.
• Auxiliary Power Output: Output that supplies 8.5 to 13.5 VDC with up to 1 amp (with
panel powered by 30 VA transformer) or 2 amps (with panel powered by 50 VA transformer)
for bus devices and hardwired detectors, such as smoke and motion detectors.
• Bus A and B: Input and output that provides communication between bus devices and the
panel.
• Siren Driver: Output that can drive an 8-ohm load and provides intrusion and fire alarm
sounds for partition 1.
• 2 Onboard Outputs: Open-collector outputs that can be set up to activate other signalling
devices, based on system events.
• Microphone Input: Input used for 2-way audio when used in conjunction with the Interro-
gator 200 Audio Verification Module.
