GE af-600 fp

Mains Supply 3 x 380 - 480 VAC
P500 P560 P630 P710 P800 P1M0
Typical Shaft output
at 400 V [kW]
500 560 630 710 800 1000
Typical Shaft output
at 460 V [HP]
650 750 900 1000 1200 1350
Unit Size IP21, 54
without/ with options
cabinet
61/63 61/63 61/63 61/63 62/64 62/64
Output current
Continuous
(at 400 V) [A]
880 990 1120 1260 1460 1720
Intermittent (60 sec
overload)
(at 400 V) [A]
968 1089 1232 1386 1606 1892
Continuous
(at 460 V) [A]
780 890 1050 1160 1380 1530
Intermittent (60 sec
overload)
(at 460 V) [A]
858 979 1155 1276 1518 1683
Continuous KVA
(at 400 V) [KVA]
610 686 776 873 1012 1192
Continuous KVA
(at 460 V) [KVA]
621 709 837 924 1100 1219
Max. input current
Continuous
(at 400 V ) [A]
857 964 1090 1227 1422 1675
Continuous (at 460 V)
[A]
759 867 1022 1129 1344 1490
Max. cable size,motor
[mm
2
(AWG
2)
)]
8x150
(8x300 mcm)
12x150
(12x300 mcm)
Max. cable size,mains
[mm
2
(AWG
2)
)]
8x240
(8x500 mcm)
Max. cable size, load-
sharing [mm
2
(AWG
2)
)]
4x120
(4x250 mcm)
Max. cable size, brake
[mm
2
(AWG
2)
)
4x185
(4x350 mcm)
6x185
(6x350 mcm)
Max. external pre-
fuses [A]
1
1600 2000 2500
Estimated power loss
at rated max. load
[W]
4)
Weight,
Unit Size IP21, IP 54
[kg]
1004/ 1299 1004/ 1299 1004/ 1299 1004/ 1299 1246/ 1541 1246/ 1541
Weight Rectifier Mod-
ule [kg]
102 102 102 102 136 136
Weight Inverter Mod-
ule [kg]
102 102 102 136 102 102
Efficiency
4)
0.98
Output frequency 0-600 Hz
Heatsink overtemp.
trip
95 °C
Power card ambient
trip
68 °C
AF-600 FP High Power Operating Instructions
155
8
