[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Line voltage out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
ID-13 Trending Mode
Option: Function:
[0] * Trend always Select Log always [0] for continuous logging.
[1] Trend once on trigger Select Log once on trigger [1] to conditionally start and stop logging using par. ID-12 Trigger Event and
par. ID-14 Samples Before Trigger.
ID-14 Samples Before Trigger
Range: Function:
50* [0 - 100] Enter the percentage of all samples prior to a trigger event which are to be retained in the log. See also
par. ID-12 Trigger Event and par. ID-13 Trending Mode.
3.16.3 ID-2# Historic Log
View up to 50 data items logged up to the last reported trip. The data is stored in array parameters, where [0] is the most recent data and [49] is the oldest data.
ID-20 Historic Log: Event
Array [50]
Range: Function:
0* [0 - 255] View the event type of the logged events.
