GE AKTAprocess User Manual

Power supply cable
The mains power supply cable is shielded ÖLFLEX™ of type:
•
CE-classified: 150CY Quattro (3 x 2.5 mm
2
)
•
UL-classified: CRF (3 x 14AWG)
If the cable needs to be replaced due to damage, the same type of cable or equivalent
must be used.
Main power supply wire colors
and tags
The power cord wires are color coded as shown in the table below. They must be con-
nected to the corresponding terminals in the fixed power supply or to a connector
compatible with IEC 60309-2.
Terminal
label
EU
(CE marking)
USA
(UL marking)
Function
L1 (Black or
brown)
BlackLive (Phase)
N2 (Blue or
black)
WhiteNeutral
PE = GNDYellow/greenGreen or Yel-
low/green
Protective
ground (earth)
Live and neutral wire cross
section area
All live and neutral wiring must have a cross section area equal to or greater than the
specification in this table:
Mains and neutral conductor
minimum area
Mains current
up to
16 AWG or 1 mm
2
10 A
14 AWG or 1.5 mm
2
16 A
12 AWG or 2.5 mm
2
25 A
ÄKTAprocess Operating Instructions 29-0252-49 AA 107
4 Installation
4.5 Power supply
