3.3.1 Structural components
Electric cabinet
The electric cabinet serves as the container for all electrical and pneumatic equipment.
Skid
The rigid stainless steel structure supports all process components and the electric
cabinet.
The structure is designed for handling in a production environment and to be easy to
move and keep clean.
The steel structure protects all installed components while still allowing easy access.
The structure occupies a small box-shaped space that makes it easy to fit into any
location in the production facility.
