8.1 Specifications
Introduction
This section contains technical data pertaining to the ÄKTAprocess and its components.
For complete technical data, refer to the GS in the product documentation package.
General technical data
The following table provides general technical data for the complete system.
ValueProperty
Inlet feed pressure: 0 to 0.2 bar (g)Process operating
limits
Outlet back pressure: 0 to 1 bar (g)
Flammable liquids: Not allowed
Operation in EX-rated environment: Not allowed
Refer to Cabinet type specific data, on page 165Electric power
Pressure 5.5 to 7 barCompressed air
Airflow min. 50 Nl/min during normal operation
System: IP55Ingress protection EN
60529
Cabinet: IP56, NEMA 4X
≤ 72 dBANoise level
Horizontal +/- 1ºFloor inclination
Up to 2000 mAltitude
Temperature: 2ºC to 26ºCAmbient environment
Air humidity: 20% to 95%, non-condensing
164 ÄKTAprocess Operating Instructions 29-0252-49 AA
8 Reference information
8.1 Specifications
