GE B90 User Manual

CHAPTER 2: PRODUCT DESCRIPTION ORDER CODES
B90 LOW IMPEDANCE BUS DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 2-9
2
CA | | | | | | | | | | PRP + six-zone 24-feeder bus protection + breaker failure
CB | | | | | | | | | | PRP + single-zone 24-feeder bus protection + breaker failure
CC | | | | | | | | | | PRP + six-zone 8-feeder bus protection + breaker failure + IEC 61850
CD | | | | | | | | | | PRP + six-zone 16-feeder bus protection + breaker failure + IEC 61850
CE | | | | | | | | | | PRP + six-zone 24-feeder bus protection + breaker failure + IEC 61850
CF | | | | | | | | | | PRP + single-zone 24-feeder bus protection + breaker failure + IEC 61850
D0 | | | | | | | | | | Six-zone 8-feeder bus protection + IEEE 1588 + CyberSentry Lvl 1
D1 | | | | | | | | | | Six-zone 16-feeder bus protection + IEEE 1588 + CyberSentry Lvl 1
D2 | | | | | | | | | | Six-zone 24-feeder bus protection + IEEE 1588 + CyberSentry Lvl 1
D3 | | | | | | | | | | Single-zone 24-feeder bus protection + IEEE 1588 + CyberSentry Lvl 1
D4 | | | | | | | | | | Six-zone 8-feeder bus protection + IEC 61850 + IEEE 1588 + CyberSentry Lvl 1
D5 | | | | | | | | | | Six-zone 16-feeder bus protection + IEC 61850 + IEEE 1588 + CyberSentry Lvl 1
D6 | | | | | | | | | | Six-zone 24-feeder bus protection + IEC 61850 + IEEE 1588 + CyberSentry Lvl 1
D7 | | | | | | | | | | Single-zone 24-feeder bus protection + IEC 61850 + IEEE 1588 + CyberSentry Lvl
1
D8 | | | | | | | | | | Six-zone 8-feeder bus protection + breaker failure + IEEE 1588 + CyberSentry Lvl
1
D9 | | | | | | | | | | Six-zone 16-feeder bus protection + breaker failure + IEEE 1588 + CyberSentry Lvl
1
DA | | | | | | | | | | Six-zone 24-feeder bus protection + breaker failure + IEEE 1588 + CyberSentry Lvl
1
DB | | | | | | | | | | Single-zone 24-feeder bus protection + breaker failure + IEEE 1588 + CyberSentry
Lvl 1
DC | | | | | | | | | | Six-zone 8-feeder bus protection + IEC 61850 + breaker failure + IEEE 1588 +
CyberSentry Lvl 1
DD | | | | | | | | | | Six-zone 16-feeder bus protection + IEC 61850 + breaker failure + IEEE 1588 +
CyberSentry Lvl 1
DE | | | | | | | | | | Six-zone 24-feeder bus protection + IEC 61850 + breaker failure + IEEE 1588 +
CyberSentry Lvl 1
DF | | | | | | | | | | Single-zone 24-feeder bus protection + IEC 61850 + breaker failure + IEEE 1588 +
CyberSentry Lvl 1
E0 | | | | | | | | | | IEEE 1588 + PRP + six-zone 8-feeder bus protection
E1 | | | | | | | | | | IEEE 1588 + PRP + six-zone 16-feeder bus protection
E2 | | | | | | | | | | IEEE 1588 + PRP + six-zone 24-feeder bus protection
E3 | | | | | | | | | | IEEE 1588 + PRP + single-zone 24-feeder bus protection
E4 | | | | | | | | | | IEEE 1588 + PRP + six-zone 8-feeder bus protection + IEC 61850
E5 | | | | | | | | | | IEEE 1588 + PRP + six-zone 16-feeder bus protection + IEC 61850
E6 | | | | | | | | | | IEEE 1588 + PRP + six-zone 24-feeder bus protection + IEC 61850
E7 | | | | | | | | | | IEEE 1588 + PRP + single-zone 24-feeder bus protection + IEC 61850
E8 | | | | | | | | | | IEEE 1588 + PRP + six-zone 8-feeder bus protection + breaker failure
E9 | | | | | | | | | | IEEE 1588 + PRP + six-zone 16-feeder bus protection + breaker failure
EA | | | | | | | | | | IEEE 1588 + PRP + six-zone 24-feeder bus protection + breaker failure
EB | | | | | | | | | | IEEE 1588 + PRP + single-zone 24-feeder bus protection + breaker failure
EC | | | | | | | | | | IEEE 1588 + PRP + six-zone 8-feeder bus protection + breaker failure + IEC 61850
ED | | | | | | | | | | IEEE 1588 + PRP + six-zone 16-feeder bus protection + breaker failure + IEC
61850
EE | | | | | | | | | | IEEE 1588 + PRP + six-zone 24-feeder bus protection + breaker failure + IEC
61850
EF | | | | | | | | | | IEEE 1588 + PRP + single-zone 24-feeder bus protection + breaker failure + IEC
61850
F0 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection
F1 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection
F2 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection
F3 | | | | | | | | | | PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection
F4 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection + IEC 61850
F5 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection + IEC 61850
F6 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection + IEC 61850
F7 | | | | | | | | | | PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection + IEC 61850
F8 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection + breaker failure
F9 | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection + breaker failure
FA | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection + breaker failure
FB | | | | | | | | | | PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection + breaker failure
FC | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection + breaker failure + IEC
61850
FD | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection + breaker failure +
IEC 61850
FE | | | | | | | | | | PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection + breaker failure +
IEC 61850
FF | | | | | | | | | | PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection + breaker failure
+ IEC 61850
G0 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection
G1 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection
G2 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection
G3 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection
G4 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection + IEC
61850
G5 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection + IEC
61850
G6 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection + IEC
61850
G7 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection + IEC
61850
G8 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection + breaker
failure
G9 | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection +
breaker failure
GA | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection +
breaker failure
GB | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection +
breaker failure
GC | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 8-feeder bus protection + breaker
failure + IEC 61850
GD | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 16-feeder bus protection +
breaker failure + IEC 61850
GE | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + six-zone 24-feeder bus protection +
breaker failure + IEC 61850
GF | | | | | | | | | | IEEE 1588 + PRP + CyberSentry Lvl 1 + single-zone 24-feeder bus protection +
breaker failure + IEC 61850
J0 | | | | | | | | | | IEC 60870-5-103 + six-zone 8-feeder bus protection
B90 - * ** - H * * - F ** - H ** - L ** - N ** - S ** - U ** - W/X ** Full Size Horizontal Mount
