CHAPTER 5: SETTINGS PRODUCT SETUP
B90 LOW IMPEDANCE BUS DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 5-37
5
RESET UNAUTH ACCESS — Resets the access restriction counter.
Selected records can be cleared from user-programmable conditions with FlexLogic operands. Assigning user-
programmable pushbuttons to clear specific records is a typical application for these commands. Since the B90 responds
to rising edges of the configured FlexLogic operands, they must be asserted for at least 50 ms to take effect.
Clearing records with user-programmable operands is not protected by the command password. However, user-
programmable pushbuttons are protected by the command password. Thus, if they are used to clear records, the user-
programmable pushbuttons can provide extra security if required.
For example, to assign user-programmable pushbutton 1 to clear demand records, apply the following settings.
1. Assign the clear demand function to pushbutton 1 by making the following change in the SETTINGS PRODUCT SETUP
 CLEAR RELAY RECORDS
menu:
CLEAR DEMAND: “PUSHBUTTON 1 ON
2. Set the properties for user-programmable pushbutton 1 by making the following changes in the
SETTINGS PRODUCT
SETUP  USER-PROGRAMMABLE PUSHBUTTONS USER PUSHBUTTON 1
menu:
PUSHBUTTON 1 FUNCTION: “Self-reset”
PUSHBTN 1 DROP-OUT TIME: “0.20 s”
5.3.6 Communications
5.3.6.1 Menu
SETTINGS PRODUCT SETUP  COMMUNICATIONS
RESET UNAUTH ACCESS:
Off
Range: FlexLogic operand
CLEAR DIR I/O STATS:
Off
Range: FlexLogic operand
Visible only for units with Direct I/O module
COMMUNICATIONS
SERIAL PORTS
See page 5-38
NETWORK
See page 5-41
IPv4 ROUTE TABLE
See page 5-44
MODBUS PROTOCOL
See page 5-46
PROTOCOL
See page 5-47
DNP PROTOCOL
See page 5-48
DNP / IEC104
POINT LISTS
See page 5-51
IEC 61850 PROTOCOL
Access in EnerVista
See page 5-52
WEB SERVER
HTTP PROTOCOL
See page 5-91
TFTP PROTOCOL
See page 5-92
IEC 60870-5-104
PROTOCOL
See page 5-92
