B90 LOW IMPEDANCE BUS DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL A-1
B90 Low Impedance Bus Differential System
Appendix A: FlexAnalog operands
Appendices
FlexAnalog operands
This appendix outlines FlexAnalog parameters.
A.1 FlexAnalog items
A FlexAnalog parameter is an analog parameter.
FlexAnalog items are also viewable in a web browser. Enter the IP address of the UR, access the Device Information Menu
option, then the FlexAnalog Parameter Listing option. Entries displayed online depend on order code.
Table A-1: FlexAnalog data items
The following addresses are given for the maximum number of physical channels. For example, if there are 7 CT
channels in the CT/VT module, that address 28437 corresponds to the "L1 Current Mag" value.
Address FlexAnalog name Units Description
8656 Bus 1 Diff Mag Amps B90 bus zone DMag
8660 Bus 1 Diff Angle Degrees B90 bus zone diff angle
8661 Bus 1 Rest Mag Amps B90 bus zone restraint RMag
8663 Bus 1 Rest Angle Degrees B90 bus zone rest angle
8664 Bus 1 Max CT Amps B90 bus max CT
8670 Bus 2 Diff Mag Amps B90 bus zone DMag
8674 Bus 2 Diff Angle Degrees B90 bus zone diff angle
8675 Bus 2 Rest Mag Amps B90 bus zone restraint RMag
8677 Bus 2 Rest Angle Degrees B90 bus zone rest angle
8678 Bus 2 Max CT Amps B90 bus max CT
8684 Bus 3 Diff Mag Amps B90 bus zone DMag
8688 Bus 3 Diff Angle Degrees B90 bus zone diff angle
8689 Bus 3 Rest Mag Amps B90 bus zone restraint RMag
8691 Bus 3 Rest Angle Degrees B90 bus zone rest angle
8692 Bus 3 Max CT Amps B90 bus max CT
8698 Bus 4 Diff Mag Amps B90 bus zone DMag
8702 Bus 4 Diff Angle Degrees B90 bus zone diff angle
