CHAPTER 6: ACTUAL VALUES RECORDS
B90 LOW IMPEDANCE BUS DIFFERENTIAL SYSTEM – INSTRUCTION MANUAL 6-11
6
6.4.4 Voltages
ACTUAL VALUES  METERING  VOLTAGES
This menu displays the metered voltage values for each terminal.
6.4.5 Frequency
ACTUAL VALUES  METERING  FREQUENCY
This menu displays the metered frequency value and the tracking frequency. The frequency is tracked based on the
selection of the reference source with the
FREQUENCY AND PHASE REFERENCE setting in the SETTINGS  SYSTEM SETUP 
POWER SYSTEM
menu. See the Power System section of chapter 5 for details.
6.4.6 RxGOOSE analogs
ACTUAL VALUES  METERING  RxGOOSE Analogs
The RxGOOSE Analog values display in this menu. The RxGOOSE Analog values are received via IEC 61850 GOOSE
messages sent from other devices.
6.5 Records
6.5.1 User-programmable fault reports
ACTUAL VALUES  RECORDS  USER-PROGRAMMABLE FAULT REPORTS
 VOLTAGES


F5 VOLTAGE:
0.000 V 0.0°

F6 VOLTAGE:
0.000 V 0.0°


S8 VOLTAGE:
0.000 V 0.0°
 FREQUENCY


FREQUENCY:
0.00 Hz

TRACKING FREQUENCY:
60.00 Hz
 RxGOOSE
 Analogs

RxGOOSE Analog 1
0.000


RxGOOSE Analog 32
0.000
The B90 is provided with optional GOOSE communications capability. This feature is specified as a software
option at the time of ordering. See the Order Codes section of chapter 2 for details.
 USER-PROGRAMMABLE
 FAULT REPORTS

NEWEST RECORD
NUMBER: 0

LAST CLEARED DATE:
2002/8/11 14:23:57
