themselves under certain circumstances. For example, you clear diagnostic information after replacement of hardware.
Once the diagnostic information is cleared, all self-checking variables are reset to their initial state and diagnostics restart
from scratch.
SAVE VOLATILE DATA — Saves this data to compact flash memory prior to shutdown. This allows the saved data to be as
recent as possible instead of relying on the periodic timer to save the data.
7.1.5 Security
COMMANDS SECURITY
With the CyberSentry option, this setting is available to enable or disable the following commands.
ADMINISTRATOR LOGOFF — Selecting ‘Yes’ allows the Supervisor to forcefully logoff an administrator session.
ENGINEER LOGOFF — Selecting ‘Yes’ allows the Supervisor to forcefully logoff an engineer session.
OPERATOR LOGOFF — Selecting ‘Yes’ allows the Supervisor to forcefully logoff an operator session.
CLEAR SECURITY DATA — Selecting ‘Yes’ allows the Supervisor to forcefully clear all the security logs and clears all the
operands associated with the self-tests.
7.2 Targets menu
A target enables the EnerVista UR Setup software to monitor automatically and display the status of any active target
messages of all the devices inserted into that site.
Each B90 element with a TARGET setting has a target message that when activated by its element is displayed in sequence
with any other currently active target messages in the
TARGETS menu. In the example shown, the Phase TOC4 and Digital
Element 48 target settings are active and so have their targets displayed. The down arrow below the two elements
indicates that there can be other active elements beyond these two.
For more information, see the description of target messages in the next section, and the Introduction to Elements section
in the Settings chapter for instructions on TARGET setting.
When no targets are active, the display reads
NO ACTIVE TARGETS.
SECURITY
ADMINISTRATOR
LOGOFF: No
Range: Yes, No
ENGINEER
LOGOFF: No
Range: Yes, No
OPERATOR
LOGOFF: No
Range: Yes, No
CLEAR SECURITY DATA:
No
Range: Yes, No
TARGETS
PHASE TOC4
OP: A B -
Displayed only if targets for this element are active.
Example shown.
DIGITAL ELEMENT 48:
LATCHED
Displayed only if targets for this element are active.
Example shown.
To Next Page
