1–4 D485 MODBUS TO DEVICENET CONVERTER – USER GUIDE
INTRODUCTION
Ordering
ORDER CODES The following table illustrates the order codes for the D485 Modbus to DeviceNet
Converter.
Specifications
MECHANICAL HOUSING
Plastic housing with snap-on connection to DIN-rail, protection class IP20
DIMENSIONS
L x W x H: 120 mm × 75 mm × 27 mm
(4.72-in × 2.95-in × 1.06-in)
PROTECTION CLASS
Protection class: IP20
ELECTRICAL
CHARACTERISTICS
POWER SUPPLY
Power: 24 V ±10% (for use in class 2 circuits)
POWER CONSUMPTION
Maximum power consumption: 280 mA on 24 V
Typically power consumption: approximately 100 mA
COMMUNICATIONS BAUD RATES
Baud rate (DeviceNet) 125, 250, and 500 kbps
Baud rate (Modbus) 1200, 2400, 4800, 9600, 19200, 38400, and 57600 bps
I/O DATA
I/O input size: 512 bytes
I/O output size: 512 bytes
FEATURES AND INTERFACE
Supported features: bit strobe, polling, cyclic and COS I/O messaging, explicit messaging
Modbus interface: RS232, RS422, RS485
DeviceNet interface: 5-pin linear DeviceNet plug (Phoenix type)
ENVIRONMENTAL RELATIVE HUMIDITY
The product is designed for a relative humidity of 0 to 95% non-condensing
TEMPERATURE
Operating: 0 to 55°C
Non Operating: –5 to 85°C
EMC COMPLIANCE CE-MARK
Certified according to European standards unless otherwise is stated
Emission: according to EN 50081-2:1993
Immunity: according to EN 61000-6-2:1999
UL/C-UL COMPLIANCE
This unit is an open type listed by the Underwriters Laboratories.
The certification has been documented by UL in file E214107.
Table 1–1: D485 order codes
D485 – *
Base unit D485 | D485 Modbus to DeviceNet Converter
C With configuration cable
X No configuration cable
