D485 MODBUS TO DEVICENET CONVERTER – USER GUIDE 2–1
D485 Modbus to DeviceNet
Converter
Chapter 2: Installation
GE
Grid Solutions
Instal lation
Quick install
PROCEDURE 1. Snap the D485 on to the DIN-rail (see DIN-rail mounting on page 2–5).
2. Connect the
DeviceNet cable (see DeviceNet connector on page 2–2).
3. Connect the serial Modbus network cable (see Modbus connector on page 2–4 for
details).
4. Connect a PC using the configuration cable (see Configuration cable on page 2–3).
5. Connect the power cable and apply power to the unit (see Power connector on page
2–4 for details).
6. Start the EnerVista P485/D485 Setup software.
7. Normally, the EnerVista P485/D485 Setup detects the correct serial port. If this does
not occur, select the correct port through the Port menu item.
8. Configure the D485 using EnerVista P485/D485 Setup and download the
configuration to the unit.
9. Configure and power-up the Modbus network device for communication.
Electrical installation
OVERVIEW The location of the various electrical connectors is shown below.
