GE D485 - Parameter Data Output Mapping Object (Class B1 H)

DATA EXCHANGE
D485 MODBUS TO DEVICENET CONVERTER – USER GUIDE 3–13
PARAMETER DATA
OUTPUT MAPPING
OBJECT (CLASS B1H)
This vendor-specific object provides parameter output data mapping information. The
number of existing attributes depends on which attributes are initialized in the module
through the EnerVista P485/D485 Setup software.
Services:
Class services: Get Attribute All
Instance services: Get Attribute Single, Set Attribute Single
Table 3–26: Class attributes for parameter data output mapping object B1h
Attr. Access Name Type Value Description
1 Get Revision UINT 0001h Revision 1
Table 3–27: Instance attributes, parameter data output mapping object, instance 01h
Attr. Access Name Type Value Description
1 Get/Set Parameter
output 1
Array of
USINT
--- Data that is read or written
2 Get/Set Parameter
output 2
Array of
USINT
--- Data that is read or written
3 Get/Set Parameter
output 3
Array of
USINT
--- Data that is read or written
↓↓↓ ↓↓ ↓
50 Get/Set Parameter
output 50
Array of
USINT
--- Data that is read or written
