ADVANCED FUNCTIONS
D485 MODBUS TO DEVICENET CONVERTER – USER GUIDE 8–11
A command and response layout example for setting 1 to 5 attributes is shown below.
Figure 8-10: Command and response layout for IO output area
Parameter Description
Command initiator Application
Command name
IO_OUTPUT_MAP
Message type 02h
Command number 0007h
Fragmented No
Extended header data ---
Command data Offset and length of the attributes to map
Response data Indicates if the message was accepted
