Introduction

Table 6-4: Pressure units triple display

At the end of rate timing, the rate of change on both channels are displayed for aeronautical units

ROC and RATE CAS and for pressure units RATE Ps, RATE Pt and RATE Qc. This is the same for all

display modes.

Option Displays

The key presses function, for the option displays, in the same way as a “single display” (i.e., the

single displayed parameter comes from the last key press), with the lower half of the display screen

showing any available data from the option.

6.2.33 SETUP, [MORE], [DISPLAYS/OPTIONS], [OPTIONS]

This function allows changes to option hardware that may be fitted. - See option manuals for

further details. If an option that is not fitted is selected the display shows the error message

“Option Hardware not fitted”. Refer to the option user manual.

6.2.34 SETUP, [MORE], [CLOSE OUTPUT VALVES]

This function closes the Ps and Pt valves to enable leak checking of the internal pneumatics of the

ADTS 405, with the aircraft system isolated, but still connected. All the normal functions of the

ADTS 405 may be used in this mode.

Note:

For safety, the output valves can only be closed when the ADTS 405 is at

ground.

6.2.35 SETUP, [MORE], [OPEN OUTPUT VALVES]

This function opens the Ps and Pt output valves after using the [CLOSE OUTPUT VALVES] function.

Note:

For safety, the output valves can only be opened when the ADTS 405 is at

ground.

6.2.36 SETUP, [MORE], [SYSTEM SELF TEST]

This function starts a self-test, the system pressures must be at ground pressure and the system in

Leak Measure mode. The self-test is the same test routine as in the power-up sequence. At the end

of the self-test the output valves open.

1st Key

Press

2nd Key

Press

Display

Any key Qc Ps, Qc

Any key Pt Ps, Qc, Pt

Ps EPR Ps, EPR

Any key ROC Ps, Qc, RATE Ps

Qc RATE Ps, Qc, RATE Qc

Pt RATE Ps, Pt, RATE Pt

EPR RATE Ps, EPR, RATE EPR

Qc Ps Ps, Qc

EPR Ps Ps, EPR
