6.2.26 SETUP
Pressing the SETUP key causes the system to enter a set-up mode preset in the configuration
mode. The following section describes the three functions of setup: Full, Minimum and Off. The full
set-up allows access to all set-up functions. Minimum set-up allows access to some set-up
functions, the off function prevents access to the set-up functions.
6.2.27 FULL SET-UP
Full set-up allows access to secondary functions that do not have an assigned key. Any parameter
changed under set-up returns to the default settings on power-down.
The CONFIGuration mode may be used to change the default settings so that the ADTS 405 powers
up in the required state. Most set-up parameters are also available under CONFIG. Additional
parameters are only available under CONFIG.
1. Certain parameters in set-up can be locked in CONFIGuration mode preventing
inadvertent changes such as aircraft limits at power-up with a particular set of limits that
must not be changed. Attempting to change a locked parameter causes the display to
show a warning message.
2. Pressing the SETUP key makes the set-up functions available. Pressing the function keys
selects the set-up menus, using the appropriate function key selects the required menu
choice. To set-up a parameter key, press SETUP then press the required parameter key.
Each parameter key set-up provides settings to the normal user mode function of the key.
Further menus are used under certain direct key set-up functions.
3. Once a setting has been changed in set-up, use CLEAR/QUIT to return to the preceding
menu. After all required parameters have been changed, repeatedly press CLEAR/QUIT
until the display shows the main pressure display.
4. The following section describes each set-up function. Intermediate menus are not
described.
Note:
The Quick Reference Section of this manual provides details of the set-up menu and
function keys.
6.2.28 SETUP, [UNITS]
a. Use [NEXT] or [PREV] to step through the available units until the display shows the
required units.
b. Select [SAVE] and then press [QUIT] to make the selection. The available units are:
ft and kts (includes Mach)
inH
2
O 4°C
ft and mph (includes Mach)
inH
2
O 20°C
m and km/h (m/min) (includes Mach)
inH
2
O 60°F
m and km/h (m/s) (includes Mach) psi
m and km/h (hm/min) (includes Mach) hPa
mbar kPa
inHg
kg/cm
2
mmHg % full-scale
