GE Druck ADTS 405 R/F Mk2 User Manual

Ventilating after Overpressure
© 2015 General Electric Company – All rights reserved. ADTS 405 Mk2 Instruction Manual-English | 63
Table 5-2: Fault Advice and Action
5.5 Ventilating after Overpressure
To calibrate or test the ADTS 405, an external pressure source is connected to the Ps and/or Pt
output connectors. If, during calibration or test procedures, an overpressure occurs, the output
valves close to protect the system.
After the valves close, pressure may be trapped in the internal system; the display may show on the
next power-up error 701:0100 or 702:0100.
CAUTION ONLY SELECT ITEMS DETAILED IN THE FOLLOWING MENUS, INCORRECT
SELECTIONS CAN CAUSE CHANGES TO SAFETY LIMITS AND THE CALIBRATION DATA OF
THE SYSTEM.
Fault Symptom Probable cause Action
F1
Pump power-on indicator
does not light.
Faulty power supply.
Unserviceable fuse, AC/DC
power supply.
Faulty power supply cable.
Check power supply.
Check/replace power supply fuse
or reset circuit protection device.
Check/replace fuse (front panel).
Replace cable and re-test.
F2
AC or DC power indicator
does not light.
AC or DC power supply cable
to 405 rack.
405 rack AC input fuse.
PSU fault.
Check/replace cables.
Check/replace fuses.
Record fault and return ADTS
405 to depot for repair.
F3
Display power-up message
appears and status light
remains red.
Internal control computer
fault.
Record fault and return ADTS
405 to depot for repair.
F4
No front panel display
power-up message, status
light green.
Display fault.
Use an available hand-terminal.
Record fault and return ADTS
405 to depot for repair.
F5
No hand-terminal display,
status light green. Hand-
terminal key illumination
on.
Hand-terminal fault (cable
OK).
Replace hand-terminal.
Record fault and return hand-
terminal to depot for repair.
F6
No hand-terminal display,
status light green. Hand-
terminal key illumination
not on.
Hand-terminal.
Replace hand-terminal.
Hand-terminal or hand-terminal
cable fault. Record fault and
return hand-terminal/cable to
depot for repair.
F7
No front panel display
DK415 message. Status
light flashing red/orange.
No front panel display
detected.
Internal fault.
Record fault and return ADTS
405 to depot for repair.
F8
No hand-terminal or front
panel display DK415
message. Status light
flashing red/orange.
No hand-terminal or front
panel display detected. Hand-
terminal fault. Cable fault.
Internal fault.
Remove hand-terminal and re-
test.
F9 Status light off. Internal PSU fault.
Record fault and return ADTS
405 to depot for repair.
F10 Status light steady orange. System fault.
Record fault and return ADTS
405 to depot for repair.
