Figure 3-6: Rate Timer Display Pressure Units
Pt Only Display (Fig 3.7)
The Pt only display overrides the other display modes (single, dual and triple). The measured
altitude and the CAS are produced from Ps in measure mode.
Figure 3-7: Pt Only Display
3.5.1.1 Change display units:
a. Press SETUP.
b. Select [MORE].
c. Select [DISPLAYS/OPTIONS].
d. Select [DISPLAY TYPE].
e. Using [NEXT] or [PREV].
f. Select either SINGLE, DUAL or TRIPLE, ENCODER (more display types with options fitted).
g. Press [SAVE] to accept.
h. Press CLEAR/QUIT repeatedly to return to user display.
Parameters
Measured
Timed
values
T for timed rate
of change
Special
message
Units of
measurement
Timed Rates
Rt Ps
Rt Pt
Rt Qc
0.637 T
0.341 T
-0.224 T
mbar/m
mbar/m
mbar/m
Alt always
shown
Measured
altitude
T for timed rate
of change
ft
kts
Selected
parameter
Aim (set-point or target)
or “leak-measure” if
Pitot controller selected o
Pointer for
parameter
Special
messages
Alt
Pt Only
CAS
Aim
407
0.0
0.0
