3. Disconnect the gas line and remove the 1/4 in.

hex screw from the rear.

4. Remove the drum.

5. Disconnect the wiring to the igniter and gas

valves.

6. Remove the two 1/4 in. hex burner bracket

mounting screws and slide the entire burner as-

sembly toward the front of the dryer to remove

from the unit.

7. Remove the three 1/4 in. hex gas valve mounting

screws and remove t he gas valve and the gas

pipe.

Igniter

Oper at i ng Volt age: 120 VAC

ResistanceaűDWURRPWHPSHUDWXUH

Igniter Removal

1. Disconnect power from the unit .

2. Remove the control panel.

3. Remove the front panel.

4. Remove the trap duct .

5. Remove the drum lamp.

6. Remove the front drum support .

7. Remove the belt .

8. Pull the drum out from the front of the dryer.

9. Remove the burner.

10. Disconnect the igniter harness.

11. Remove the one 1/4 in. hex screw and remove

the igniter.

12. Make sure the igniter harness is routed through

the burner bracket hole.

Flame Detector

Fl am e Det ect or Rem ova l

1. Disconnect power from the unit .

2. Remove the control panel.

3. Remove the front panel.

4. Remove the trap duct .

5. Remove the drum lamp.

6. Remove the front drum support .

7. Remove the belt .

8. Pull the drum out the front of the dryer.

9. 'LVFRQQHFWWKHÀDPHGHWHFWRUKDUQHVV

10. 5HPRYHWKHÀDPHGHWHFWRUPRXQWLQJVFUHZ

11. 5HPRYHWKHÀDPHGHWHFWRU

See D r u m Rem o v a l o n p a g e 35 .

See I g n i t e r L o c a t i o n o n p a g e 4 4 .

See Co n t r o l Pa n e l Rem o v a l o n p a g e 2 0 .

See Fr o n t Pa n e l Re m o v a l o n p a g e 2 4 .

See Tr a p D u c t Rem o v a l o n p a g e 38 .

See L ED D r u m L a m p Re m o v a l o n p a g e 3 3.

See I n c a n d es c en t D r u m La m p Rem o v a l o n

page 34.

See Fl a m e D et e c t o r Lo c a t i o n o n p a g e 4 4 .
