St e a m Co m p o n e n t s
Steam Tube
Mist Nozzle
Nozzle Holder
Steam Elbow
Water Valve
Retainer
Mist Nozzle
Th e m i st n ozzl e i s l oc a t ed i n si d e t h e d r yer o n t h e l ef t
side of the rear bulkhead. The mist nozzle consists
RIDEUDVVRUL¿FHDQGD¿QH¿OWHUVFUHHQ,IWKHRUL¿FH
should become plugged or restricted, it should not
be cleaned. Replace a plugged or restricted misting
nozzle.
Nozzle Holder
Nozzle Holder Removal
1. Disconnect the steam tube from the water valve.
2. Remove the nozzle retainer by twisting slightly
counter-clockwise.
Wat er Valve
Oper at i ng Volt age: 120 VAC
ResistanceaNű
Wat er Valve Removal
1. Disconnect power and water from the unit .
2. Remove the control panel.
3. Remove the top panel.
4. Disconnect the water valve wire harness and the
water line.
5. Remove the 1/4 in. hex screw that holds the wa-
ter valve in place.
1/4" hex
6. Slide the water valve slightly left to remove.
See Co n t r o l Pa n e l Rem o v a l o n p a g e 2 0 .
See To p Pa n el Rem o v a l o n p a g e 24 .
