GE
D
IRECTION 5535208-100, REV. 2 LOGIQ E9 SERVICE MANUAL
Chapter 8 Replacement procedures 8 - 41
8-5-5 Side Bumpers replacement
8-5-5-1 Side Bumpers removal
8-5-5-2 Side Bumpers installation
Table 8-15 Manpower / Time and Tools
Manpower /
Time
Tools
One person /
15 minutes
Refer to: 8-2-5 "Tools needed for servicing the LOGIQ E9" on page 8-5.
Table 8-16 Preparations and Preparation Links
Preparations - you must perform the following steps
1. Power down the system.
2. Disconnect the mains power cable from the wall outlet and all Probes and External I/O Cabling.
3. Remove the Side Cover(s).
Preparation Links (if you need more information):
• 4-2-3 "Power shut down" on page 4-7.
• 8-5-2 "Side Covers replacement" on page 8-30.
Table 8-17 Side Bumpers removal
Steps
Corresponding Graphic
1. Unscrew and remove the six screws and washers that fasten the Side Bumper to the Side Cover.
Remove the Side Bumper from the Side Cover.
Table 8-18 Side Bumpers installation
Steps
Corresponding Graphic
1. Align the fastening holes in the Side Bumper with the holes in the Side Cover.
Fasten the screws with washer, one by one until all have been inserted.
Tighten the screws.
2. Install the Side Cover(s).
